Cub Cadet 1440 Lawn Tractor
The
Cub Cadet 1440 garden tractor was manufactured from 1992 to 1997. The Cub Cadet
1440 powerline components: Briggs and Stratton 294447 Vanguard 4-stroke V-twin
cylinder OHV forced-air gasoline engine and Sundstrand shaft driven hydrostatic
transmission with infinite forward and reverse gears.
A 29.3 cu.in (480 cc) engine has a cylinder bore of 2.67" (68 mm),
piston stroke of 2.61" (66 mm), and max power of 14 hp (10.5 kW). The
maximum travel speed (forward/reverse): 7.5 mph (12.1 km/h) and 4 mph
(6.4 km/h).
The Cub Cadet 1440 was equipped with a manual steering, dual disc
brakes, 16x6.50-8 front tires, and 23x10.50-12 rear tires. The wheelbase
is 46.5" (1180 mm). The tractor is compatible with 42" or 44" mid-mount
3-blade mower decks with cutting height of 1.0-4.5 in (25-115 mm) and
mechanical lifting system.
| Engine Model |
Briggs and Stratton 294447 Vanguard |
| Engine Type |
Gasoline, 4-stroke, 2-cylinder V-Twin OHV |
| Number of Cylinders |
2 |
| Displacement, cu in (L) |
29.3 (0.480) |
| Engine Bore, in (mm) |
2.67 (68.0) |
| Engine Stroke, in (mm) |
2.61 (66.0) |
| Maximum Engine Power, hp (kW) |
14.0 (10.5) |
| Rated Engine Speed, rpm |
3600 |
| Idle Speed, rpm |
1750 |
| Fuel System |
Carburetor |
| Cooling System |
Forced-air |
| Armature Air Gap, in (mm) |
0.008-0.012 (0.20-0.30) |
| Spark Plug Gap, in (mm) |
0.030 (0.76) |
| Intake Valve Clearance (Cold), in (mm) |
0.004-0.006 (0.10-0.15) |
| Exhaust Valve Clearance (Cold), in (mm) |
0.004-0.006 (0.10-0.15) |
| Valve Guide, in (mm) |
0.2365-0.2371 (6.01-6.02) |
| Valve Stem (Intake), in (mm) |
0.2340-0.2346 (5.95-5.96) |
| Valve Stem (Exhaust), in (mm) |
0.2338-0.2340 (5.94-5.95) |
| Crankshaft End Play, in (mm) |
0.003-0.015 (0.08-0.40) |
| Fuel Tank Capacity, gal (L) |
5.0 (19.0) |
| Oil Capacity, qts (L) |
1.9 (1.8) |
| Electrical System Rating, Volts |
12 |
| Charging System |
Alternator 15A |
| Starter Type |
Electric |
| Number of Batteries |
1 |
| Battery Voltage, Volts |
12 |
| Electric Ground |
Negative |
| PTO Location |
Front |
| Front PTO Operational Type |
Independent |
| Front PTO Clutch |
Electric |
| Transmission Type |
Shaft driven hydrostatic |
| Transmission Model |
Sundstrand |
| Forward/Reverse Gears |
Infinite |
| Oil Capacity, qts (L) |
7.0 (6.6) |
| Maximum Forward Speed, mph (kph) |
7.5 (12.1) |
| Maximum Reverse Speed, mph (kph) |
4.0 (6.4) |
| Drive Wheels |
2WD 4x2 |
| Steering Configuration |
Front steer |
| Steering System |
Manual |
| Brakes Type |
Dual disc |
| Front Tire Size |
16x6.50-8 |
| Rear Tire Size |
23x10.50-12 |
| Wheelbase, in (mm) |
46.5 (1180) |
| Length, in (mm) |
72 (1820) |
| Height, in (mm) |
44 (1110) |
| Overall Width, in (mm) |
37.8 (950) |
| Ground Clearance, in (mm) |
6 (150) |
| Weight, lb (kg) |
760 (345) |
| Mower Deck Type |
Mid-mount |
| Number of Blades |
3 |
| Cutting Width, in (mm) |
42 (1060) |
| Cutting Height, in (mm) |
1.0-4.5 (25-115) |
| Lift System |
Mechanical |
| Mower Deck Type |
Mid-mount |
| Number of Blades |
3 |
| Cutting Width, in (mm) |
44 (1110) |
| Cutting Height, in (mm) |
1.0-4.5 (25-115) |
| Lift System |
Mechanical |
