Wheel Horse C-161 Garden Tractor
The
Wheel Horse C161 garden tractor was manufactured between 1978 and 1979. The
Wheel Horse C-161 tractor could be powered by two engines: 35.9 cu.in (588 cc)
Kohler K341AS single cylinder air-cooled gasoline engine with a rated power of
16 Hp (12 kW), or 40 cu.in (655 cc) Briggs and Stratton 401407 twin cylinder
horizontal shaft air-cooled gasoline engine with a rated power of 16 Hp (12 kW).
Tractor is fitted with 2 types of transmission. 1st type: belt-driven
gear transmission with 6 forward and 2 reverse gears. 2nd type:
Sundstrand belt-driven hydrostatic transmission with infinite forward
and reverse gears.
Max forward speed - 6.3 mph (10.1 km/h), maximum reverse speed - 3.2 mph
(5.1 km/h). The Wheel Horse C161 was equipped with a manual steering
system, drum type brakes, 16x6.50-8 front tires, and 23x8.50-12 rear
tires. The wheel base is 45.5" (1150 mm). The tractor is compatible with
the following attachments: 36", 42" mid-mount 3-blade right-discharge
mower decks with cutting height of 1.25-3.25" (31-82 mm), 48" mid-mount
3-blade right-discharge mower deck with cutting height of 1.5-4.0"
(38-102 mm), 42" front-mount snow blower, and 42" front-mount blade.
| Engine Model |
Kohler K341AS |
| Engine Type |
4-Cycle single cylinder air-cooled gasoline |
| Number of Cylinders |
1 |
| Displacement, cu.in (L) |
35.9 (0.588) |
| Engine Bore, in (mm) |
3.75 (95.4) |
| Engine Stroke, in (mm) |
3.25 (82.6) |
| Maximum Horse Power, hp (kW) |
16.0 (12.0) |
| Rated Engine Speed, rpm |
3600 |
| Crankshaft Alignment |
Horizontal |
| Fuel System |
Carburetor |
| Carburetor Model |
Kohler/Walbro |
| Carburetor Type |
Fixed main jet or adjustable main jet |
| Lubrication System |
Splash type |
| Cooling System |
Forced-air |
| Ignition System |
Battery |
| Spark Plug Type |
Champion RH10 |
| Spark Plug Size, in (mm) |
0.553 (14.0) |
| Spark Plug Gap, in (mm) |
0.0256 (0.65) |
| Breaker Point Gap (Nominal), in (mm) |
0.020 (0.50) |
| Valve Clearance (Intake), in (mm) |
0.008-0.010 (0.20-0.25) |
| Valve Clearance (Exhaust), in (mm) |
0.017-0.019 (0.43-0.48) |
| Fuel Tank Capacity, gal (L) |
3.0 (11.5) |
| Oil Capacity, qt (L) |
2.26 (2.21) |
| Engine Model |
Briggs and Stratton 401407 |
| Engine Type |
4-cycle twin cylinder horizontal shaft air-cooled gasoline engine |
| Number of Cylinders |
2 |
| Displacement, cu.in (cc) |
40.0 (655) |
| Cylinder Bore, in (mm) |
3.44 (87.0) |
| Piston Stroke, in (mm) |
2.16 (55.0) |
| Rated Engine Power, hp (kW) |
16.0 (11.9) |
| Rated Engine Speed, rpm |
3600 |
| Idle Speed, rpm |
1200-1400 |
| Maximum Torque, Nm (ft-lbs) |
34.8 (25.8) |
| Torque Speed, rpm |
2700 |
| Fuel System Type |
Carburetor |
| Carburetor Type |
Float |
| Governor Type |
Mechanical |
| Cylinder Bore Type |
Cast iron sleeve |
| Lubrication System |
Full pressure |
| Air Cleaner |
Paper cartridge with a foam pre-cleaner |
| Cooling System |
Forced air |
| Ignition System |
Flywheel magneto |
| Spark Plug Type |
Champion RJ-12, Autolite 308 |
| Spark Plug Gap, in (mm) |
0.03 (0.76) |
| Point Gap, in (mm) |
0.020 (0.51) |
| Valve Clearance (Intake), in (mm) |
0.004-0.006 (0.10-0.15) |
| Valve Clearance (Exhaust), in (mm) |
0.007-0.009 (0.18-0.23) |
| Fuel Tank Capacity, gal (L) |
3.0 (11.5) |
| Oil Capacity, qts (L) |
1.75 (1.70) |
| Electrical System Rating, Volts |
12 |
| Starter Type |
Electric |
| Number of Batteries |
1 |
| Electric Ground |
Negative |
| Front PTO Operational Type |
Independent |
| Front PTO Clutch |
Mechanical |
| Front PTO Speed, rpm |
3200 |
| Transmission Model |
Wheel Horse |
| Transmission Type |
Belt-driven gear |
| Gearbox Type |
6F/2R, Hi-Lo |
| Number of Forward Gears |
6 |
| Number of Reverse Gears |
2 |
| Oil Capacity, qts, (L) |
2.0 (1.9) |
| Maximum Forward Speed, mph (kph) |
5.5 (8.8) |
| Maximum Reverse Speed, mph (kph) |
2.6 (4.2) |
| Transmission Model |
Sundstrand |
| Transmission Type |
Belt-driven hydrostatic |
| Number of Forward Gears |
Infinite |
| Number of Reverse Gears |
Infinite |
| Oil Capacity, qts, (L) |
5.5 (5.2) |
| Maximum Forward Speed, mph (kph) |
6.3 (10.1) |
| Maximum Reverse Speed, mph (kph) |
3.2 (5.1) |
| Drive Wheels |
2WD 4x2 |
| Steering Configuration |
Front steer |
| Steering System |
Manual |
| Front Tire Size |
16x6.50-8 |
| Rear Tire Size |
23x8.50-12 |
| Wheelbase, in (mm) |
45.5 (1150) |
| Length, in (mm) |
65 (1650) |
| Height, in (mm) |
41 (1040) |
| Overall Width, in (mm) |
36 (910) |
| Weight (Gear and Kohler Engine), lb (kg) |
600 (272) |
| Weight (Hydro and Kohler Engine), lb (kg) |
640 (290) |
| Weight (Gear and Briggs Twin Engine), lb (kg) |
565 (256) |
| Weight (Hydro and Briggs Twin Engine), lb (kg) |
605 (274) |
| Mower Deck Type |
Mid-mount, rear-discharge |
| Number of Blades |
3 |
| Cutting Width, in (mm) |
36 (910) |
| Cutting Height, in (mm) |
1.25-3.25 (32-82) |
| Deck Drive |
Belt |
| Lift System |
Manual |
| Mower Deck Type |
Mid-mount, right-discharge |
| Number of Blades |
3 |
| Cutting Width, in (mm) |
42 (1060) |
| Cutting Height, in (mm) |
1.50-3.25 (32-82) |
| Deck Drive |
Belt |
| Lift System |
Manual |
| Mower Deck Type |
Mid-mount, right-discharge |
| Number of Blades |
3 |
| Cutting Width, in (mm) |
48 (1215) |
| Cutting Height, in (mm) |
1.5-4.0 (38-102) |
| Deck Drive |
Belt |
| Lift System |
Manual |
| Snowblower Type |
Front-mount |
| Clearing Width, in (mm) |
42 (1060) |
| Lift System |
Manual |
| Blade Type |
Front-mount |
| Width, in (mm) |
42 (1060) |
| Lift System |
Manual |
| Angle |
Manual |
