Ford 768B Front End Loader
The
Ford 768B front end loader is designed to fit Ford 1110, 1210 tractors. The
loader hydraulic system includes double-acting hydraulic bucket and lifting
cylinders.
The loader’s max lift height is 70 inches (1771 mm) at pin, and bucket
dump clearance is 52 inches (1316 mm). The lifting capacity is 530 lbs
(241 kg) to max height at pin, and bucket's breakout force is 980 lbs
(445 kg). The raising time is 6 seconds from ground level to full
height, and bucket rollback time is 4 sec.
The Ford 768B loader is equipped with a 40" (1010 mm) standard material
bucket with a heaped capacity of 6.3 cu.ft (0.15 m3), or 48" (1220 mm)
standard material bucket with a heaped capacity of 7.5 cu.ft (0.21 m3).
| Tractor models |
Ford 1110, 1210 |
| Front tires |
5.00x12 |
| Rear tires |
8.00x16 |
| Hydraulic system flow, gpm (lpm) |
4.3 (16.5) |
| Hydraulic pressure, bar (psi) |
127 (1850) |
| Loader model |
Ford 768B |
| Attachment control type |
Hydraulic/Mechanical |
| Weight, lbs (kg) |
540 (245) |
| 40" Standard Material Bucket |
| Width, in (mm) |
40 (1010) |
| Depth, in (mm) |
18 (455) |
| Height, in (mm) |
19 (480) |
| Capacity (Struck), cu.ft (m3) |
4,9 (0,14) |
| Capacity (Heaped), cu.ft (m3) |
6,3 (0,15) |
| Weight, lbs (kg) |
200 (90) |
| 48" Standard Material Bucket |
| Width, in (mm) |
48 (1220) |
| Depth, in (mm) |
18 (455) |
| Height, in (mm) |
19 (480) |
| Capacity (Struck), cu.ft (m3) |
6,0 (0,17) |
| Capacity (Heaped), cu.ft (m3) |
7,5 (0,21) |
| Weight, lbs (kg) |
230 (105) |
| Maximum lift height at pivot pin, in (mm) |
70 (1771) |
| Reach at maximum height, in (mm) |
23 (582) |
| Clearance, bucket dumped, in (mm) |
52 (1316) |
| Maximum dumping angle, degrees |
40 |
| Reach, bucket on ground, in (mm) |
47.5 (1202) |
| Rollback angle, degrees |
8 |
| Maximum digging depth, in (mm) |
4.5 (114) |
| Lift capacity to maximum height at pivot pin, lbs (kg) |
530 (241) |
| Breakout force at pivot pin, lbs (kg) |
980 (445) |
| Raising time to full height, sec |
6,0 |
| Lowering time, sec |
3,5 |
| Bucket rollback time, sec |
4,0 |
