Massey Ferguson FL.3419 X Loader

The MF FL.3419 X loader is available for Massey Ferguson 4707, 4708, 4709 tractors. The MF FL.3419X loader has double acting hydraulic lifting and bucket cylinders. The loader’s maximum lift height is 134.4" (3400 mm) at pin and max bucket dump angle of 50 degrees. The lifting capacity is 3410 lbs (1550 kg) at maximum height (bucket pin), and breakout force (bucket on ground) is 5192 lbs (2360 kg).

Compatible buckets for the Massey Ferguson FL.3419 X front-end loader: 63" (1600 mm) and 73" (1850 mm) standard material buckets with heaped capacities of 0.65 m3 (23 cu.ft) and 0.72 m3 (25.4 cu.ft), or 85" (2150 mm) grading bucket with a heaped capacity of 0.73 m3 (25.8 cu.ft), and 73" (1850 mm) heavy-duty material bucket with a heaped capacity of 0.72 m3 (25.4 cu.ft).

Compatible Tractors
Tractor models Massey Ferguson 4707, 4708, 4709
Hydraulic system flow, gpm (lpm) 17.0 (65.0)
Hydraulic pressure, bar (psi) 200 (2900)

Loader
Loader model MF FL.3419 X
Leveling system Non self leveling
Lift cylinder diameter, in (mm) 2.77 (70)
Bucket cylinder diameter, in (mm) 2.77 (70)
Weight (w/o bucket), lb (kg) 737 (335)

63" Standard Material Bucket
Width, in (mm) 63 (1600)
Depth, in (mm) 31.9 (810)
Height, in (mm) 29.5 (750)
Capacity (heaped), cu.ft (m3) 23 (0.65)
Weight, lb (kg) 365 (166)

73" Standard Material Bucket
Width, in (mm) 73 (1850)
Depth, in (mm) 31.9 (810)
Height, in (mm) 29.5 (750)
Capacity (heaped), cu.ft (m3) 25.4 (0.72)
Weight, lb (kg) 450 (205)

Heavy Duty Material Bucket
Width, in (mm) 73 (1850)
Depth, in (mm) 31.9 (810)
Height, in (mm) 29.5 (750)
Capacity (heaped), cu.ft (m3) 25.4 (0.72)
Weight, lb (kg) 500 (227)

Loader Dimensions
Maximum lift height at pivot pin, in (mm) 134.4 (3400)
Maximum lift height under level bucket, in (mm) 126.5 (3200)
Maximum dump angle at maximum height, deg 50
Maximum rollback angle at ground level, deg 44

Operating Data
Lift capacity to maximum height at pivot pin, lb (kg) 3410 (1550)
Lift capacity to maximum height at 31.5" (800 mm) from pivot pin, lb (kg) 2134 (970)
Lift capacity to 59" (1.5m) height at pivot pin, lb (kg) 4136 (1880)
Lift capacity to 59" (1.5m) height at 31.5" (800 mm) from pivot pin, lb (kg) 3014 (1370)
Breakout force at pivot pin, lb (kg) 5192 (2360)
Breakout force at 31.5" (800 mm) from pivot pin, lb (kg) 3520 (1600)
Rollback force at ground level, lb (kg) 4202 (1910)
