Ford 675D Backhoe Loader
The
Ford 675D is a 2-wheel drive or 4-wheel drive backhoe loader. This model was
manufactured between 1993 and 1995. The Ford 675D drivetrain components: a
4-cyl. direct injection turbocharged diesel engine, and 4-speed fully
synchronized transmission with a torque converter.
A 268 cubic inches (4.4 L) engine power is 93 Hp (69.4 kw), and a max.
torque is 317 Nm (233 lb-ft) at 1200 rev/min. The maximum forward speed
- 19.9 mph (32 km/h), a max reverse speed - 19.8 mph (31.9 km/h). The
open center hydraulic system used a gear pump with fluid flow rate of 31
gpm (117.5 lpm).
The main relief pressure is 183 bar (2650 psi). The 2-wheel drive models
are equipped with 11Lx16 front tires and 16.9x28 rear tires. The
12.0x16.5 front tires and 16.9x28 rear tires are used for models with
4-wheel drive.
The loader has a lift capacity (at pin) of 6500 lbs (2950 kg) to a max
height of 136.3 in (3460 mm), and a breakout force of 12000 lbs (5445
kg). The bucket dump clearance is 106.6 in (2700 mm) at maximum dump
angle of 45 degrees. The rated cycle times are 4.5 seconds raising to
full height, and 1.7 seconds maximum bucket dumping. The loader bucket
has a heaped capacity of 1.51 cu.yd (1.10 m3) and width of 88 in (2230
mm).
The backhoe digs to a maximum depth of 186 in (4720 mm). The digging
force is 11170 lbs (5065 kg) for the bucket cylinder and 7680 lbs (3485
kg) for the dipperstick cylinder. The overall reach from swing pivot at
ground level is 233 in (5910 mm). The backhoe is compatible with 12",
18", 24", 30", and 36" buckets.
Engine Model |
Ford |
Engine Type |
4-Stroke, four-cylinder turbocharged diesel |
Number of Cylinders |
4 |
Displacement, cu in (L) |
268 (4.40) |
Engine Bore, in (mm) |
4.40 (112.0) |
Engine Stroke, in (mm) |
4.40 (112.0) |
Aspiration |
Turbocharged |
Rated Engine Power, hp (kW) |
93.0 (69.4) |
Rated Engine Speed, rpm |
2200 |
Maximum Torque, Nm (ft-lb) |
317 (233) |
Torque Speed, rpm |
1200 |
Compression Ratio |
16.3:1 |
Firing Order |
1-3-4-2 |
Fuel System |
Direct injection |
Injection Pump Type |
Rotary |
Governor Type |
Mechanical |
Air Cleaner |
Dual dry element |
Intake Valve Clearance, in (mm) |
0.015 (0.38) |
Exhaust Valve Clearance, in (mm) |
0.018 (0.46) |
Fuel Tank Capacity, gal (L) |
24.0 (90.8) |
Oil Capacity, qts (L) |
9.0 (8.5) |
Coolant Capacity, qts (L) |
16.9 (16.0) |
Electrical System Rating, Volts |
12 |
Charging System |
Alternator |
Alternator Rating, Amps |
55 |
Transmission Type |
Torque Converter |
Gearbox Type |
4F/4R, Fully synchronized |
Number of Forward Gears |
4 |
Number of Reverse Gears |
4 |
Torque Converter Type |
Single stage |
Torque Converter Ratio |
2.78:1 |
Oil Capacity, qts (L) |
17.0 (16.1) |
Maximum Forward Speed, mph (kph) |
19.9 (32.0) |
Maximum Reverse Speed, mph (kph) |
19.8 (31.9) |
Drive Wheels |
2WD/4WD |
Steering Configuration |
Front steer |
Steering System |
Hydrostatic power |
Brakes Type |
Wet disc |
Front Tire Size (2WD) |
11Lx16 |
Rear Tire Size (2WD) |
16.9x28 |
Front Tire Size (4WD) |
12.0x16.5 |
Rear Tire Size (4WD) |
16.9x28 |
Front Tread, in (mm) |
68.5-70 (1730-1770) |
Rear Tread, in (mm) |
68 (1720) |
Hydraulic System Type |
Open Center |
Hydraulic Pump Type |
Gear |
Implement Pump Flow, gpm (Lpm) |
31.0 (117.5) |
Steering Pump Flow, gpm (Lpm) |
5.1 (19.5) |
Hydraulic Pressure, Bar (psi) |
183 (2650) |
Steering Pressure, Bar (psi) |
134 (1950) |
Hydraulic Fluid Capacity, gal (L) |
21.0 (79.5) |
Steering Oil Capacity, qts (L) |
2.4 (2.3) |
Wheelbase, in (mm) |
87 (2200) |
Length (with Backhoe/Loader), in (mm) |
280 (7110) |
Height (Cab), in (mm) |
109 (2760) |
Height (ROPS), in (mm) |
108 (2740) |
Overall Width, in (mm) |
87 (2200) |
Ground Clearance (2WD), in (mm) |
11.5 (290) |
Ground Clearance (4WD), in (mm) |
11 (280) |
Weight with Backhoe/Loader (2WD), lb (kg) |
13640 (6200) |
Weight with Backhoe/Loader (4WD), lb (kg) |
15180 (6900) |
Loader Model |
Ford |
Maximum Lift Height (to Pin), in (mm) |
136.3 (3460) |
Clearance, Dumped Bucket, in (mm) |
106.6 (2700) |
Reach At Max. Lift Height, in (mm) |
26.7 (670) |
Dump Angle, deg |
45 |
Rollback Angle, deg |
40 |
Breakout Force (at Pin), lb (kg) |
12000 (5445) |
Lift Capacity To Max. Height (at Pin), lb (kg) |
6500 (2950) |
Bucket Width, in (mm) |
88 (2230) |
Raising Time to Full Height, sec |
4.5 |
Bucket Dumping Time, sec |
1.7 |
Lowering Time, sec |
2.8 |
Backhoe Model |
Ford |
Digging Depth, in (mm) |
186 (4720) |
2-ft Flat Digging Depth, in (mm) |
185 (4690) |
8-ft Flat Digging Depth, in (mm) |
171 (4340) |
Reach from Swing Pivot, in (mm) |
233 (5910) |
Loading Height, in (mm) |
150 (3810) |
Swing Arc, deg |
166 |
Bucket Arc, deg |
180 |
Maximum Transport Height, in (mm) |
153 (3880) |
Bucket Digging Force, lb (kg) |
11170 (5065) |
Dipperstick Digging Force, lb (kg) |
7680 (3485) |
Bucket Width, in (mm) |
12 (305) |
Bucket Width, in (mm) |
18 (455) |
Bucket Width, in (mm) |
24 (605) |
Bucket Width, in (mm) |
30 (760) |
Bucket Width, in (mm) |
36 (910) |
