Ford 1910 Tractor Maintenance
The
Ford 1910 compact utility tractor was manufactured between 1983 and 1986. The
Ford 1910 driveline components: Shibaura T853A 3-cylinder in-line liquid cooled
diesel engine and 12x4 unsynchronized gear transmission, or partially
synchronized gear transmission with 12 forward and 4 reverse gears.
A 103.8 cubic inches (1.7 L) engine has a cylinder bore of 3.35 inches
(85 mm), piston stroke of 3.94 inches (100 mm), and rated power of 32 hp
(23.9 kW). Max. forward speed - 13.5 mph (21.7 km/h), max. reverse speed
- 11.6 mph (18.5 km/h).
The open center hydraulic system includes a gear pump with a rated
capacity of 8.6 gallons per minute (32.5 liters per minute). The
hydraulic pressure is 147 bar (2135 psi). The 2WD models are equipped
with 5.50-16 front tyres and 13.6-24 rear tyres. The 27x8.50-15 front
tyres and 18.4x16.1 rear tyres fit 4WD tractors. The wheel base is 66.3
inches (1680 mm) for 2-wheel drive models and 66.9 inches (1690 mm) for
4-wheel drive models.
The Ford 1910 tractor is compatible with the following attachments: a
60" mid-mount 3-blade mower deck, 60" rear-mount 2-stage snowblower with
a hydraulic lift system, Ford 770B loader with a lift capacity to full
height of 1130 lbs (512 kg), and Ford 758A backhoe with a 2-foot flat
digging depth of 94 inches (2380 mm).
| Engine oil capacity, qts (L) |
6.9 (6.5) |
| Engine coolant capacity, qts (L) |
7.4 (7.0) |
| Transmission/Hydraulic system capacity, gal (L) |
7.4 (28.0) |
| Front axle oil capacity, qts (L) |
5.3 (5.0) |
| Recommended Oil and Fluid |
| Engine oil type |
SAE 10W-40, 15W-40, 10W-30, SAE 10W |
| Engine coolant type |
Antifreeze/Coolant |
| Transmission/Hydraulic fluid type |
134D, SAE 10W-30 |
| Front axle oil type |
134D, Gearlube 80W-90 |
| Check engine oil level |
Every 10 hours |
| Check the hydraulic/transmission fluid level |
Every 10 hours |
| Check engine air filter |
Every 10 hours |
| Check coolant level in radiator |
Every 10 hours |
| Check battery and clean terminals |
Every 50 hours |
| Check front axle oil |
Every 50 hours |
| Inspect and adjust alternator belt |
Every 50 hours |
| Lubricate axle hub bearings |
Every 50 hours |
| Change engine oil |
Every 100 hours |
| Clean engine air filter |
Every 100 hours |
| Clean engine fuel filter |
Every 100 hours |
| Replace engine oil filter |
Every 200 hours |
| Replace engine fuel filter |
Every 200 hours |
| Adjust parking and service brakes |
Every 200 hours |
| Change hydraulic/transmission fluid |
Every 300 hours |
| Change front axle lubricant |
Every 300 hours |
| Replace hydraulic oil filter |
Every 300 hours |
| Replace engine air filter |
Every 500 hours |
| Check and adjust engine idling |
Every 500 hours |
| Check and adjust valve clearance |
Every 500 hours |
| Flush cooling system and add new coolant |
Every 1000 hours |
| Engine oil filter part number |
86546613, E1NN6714BB |
| Engine fuel filter part number |
87300041 |
| Engine air filter part number |
84539171, 86512889 |
| Hydraulic oil filter part number |
4245130 |
