International Harvester 786 Specs
The
International Harvester 786 two-wheel drive row-crop tractor was manufactured
between 1980 and 1981. The IH 786 driveline consists of International Harvester
D358 six-cylinder liquid-cooled diesel engine and two-speed powershift Torque
Amplifier transmission with 16 forward and 8 reverse gears.
A 358 cu.in (5.9 L) engine has a cylinder bore of 3.88" (98 mm),
piston stroke of 5.06" (129 mm), and rated power of 89 hp (66 kW). The
max forward speed - 19.1 mph (30.7 km/h), max reverse speed -
9.4 mph (15.1 km/h). The open center hydraulic system includes a gear
pump with rated fluid flow of 12 gpm (45.4 lpm).
The hydraulic system
pressure is 172 bar (2500 psi). The International Harvester 786 is
equipped with a hydrostatic power steering system, hydraulic wet disc
brakes, 9.5Lx15 front tyres, and 18.4x34 rear tyres. The wheelbase is
101 in (2560 mm).
Engine Model |
International Harvester D358 |
Engine Type |
4-stroke, 6-cylinder liquid-cooled diesel |
Number of Cylinders |
Six |
Displacement, cu in (L) |
358 (5.90) |
Engine Bore, in (mm) |
3.88 (98.0) |
Engine Stroke, in (mm) |
5.06 (129.0) |
Aspiration |
Natural |
Rated Engine Power, hp (kW) |
89.0 (66.0) |
Rated Engine Speed, rpm |
2400 |
Idle Speed, rpm |
850-2500 |
Compression |
14.8:1 |
Firing Order |
1-5-3-6-2-4 |
Fuel System |
Direct injection |
Fuel Tank Capacity, gal (L) |
50.0 (189.3) |
Oil Capacity, qts (L) |
12.0 (11.4) |
Coolant Capacity, qts (L) |
24.0 (22.7) |
Electrical System Rating, Volts |
12 |
Charging System |
Alternator |
Alternator Rating, Amps |
42/61 |
PTO Operational Type |
Independent |
PTO Horsepower, hp (kW) |
80.2 (59.8) |
PTO Clutch |
Dry disc |
PTO Speeds, rpm |
540/1000 |
PTO / Engine Speed, rpm |
540/2106 |
PTO / Engine Speed, rpm |
1000/2072 |
Transmission Type |
Torque Amplifier |
Gearbox Type |
16F/8R, 2-speed powershift |
Number of Forward Gears |
16 |
Number of Reverse Gears |
8 |
Clutch Type |
Dry disc |
Oil Capacity, qts (L) |
90.0 (85.2) |
Maximum Forward Speed, mph (kph) |
19.1 (30.7) |
Maximum Reverse Speed, mph (kph) |
9.4 (15.1) |
Drive Wheels |
2WD 4x2 |
Steering Configuration |
Front Steer |
Steering System |
Hydrostatic power |
Brakes Type |
Hydraulic wet disc |
Front Tire Size |
9.5L-15 |
Rear Tire Size |
18.4-34 |
Front Tread, in (mm) |
60-84 (1675-2880) |
Rear Tread, in (mm) |
66-113.5 (1820) |
Hydraulic System Type |
Open Center |
Implement Pump Type |
Gear |
Implement Pump Flow, gpm (Lpm) |
12.0 (45.4) |
Hydraulic Fluid Capacity, qts (L) |
22.4 (85.2) |
3-Point Hitch Category |
2/1 |
Wheelbase, in (mm) |
101 (2560) |
Length, in (mm) |
165 (4190) |
Height (ROPS), in (mm) |
112 (2840) |
Overall Width, in (mm) |
102 (2590) |
Ground Clearance, in (mm) |
13 (330) |
Turning Radius (with Brake), in (mm) |
143 (3610) |
Turning Radius (without Brake), in (mm) |
175 (4420) |
Weight (Shipping), lb (kg) |
10600 (4810) |
Weight (Operating), lb (kg) |
11590 (5255) |
