Massey Ferguson 1760M Tractor
The
Massey Ferguson 1760M compact utility tractor was manufactured from 2018 to
2021. The MF 1760M tractor is powered by Shibaura N4LDI-T 4 stroke 4-cylinder
direct injection liquid-cooled diesel engine. A 135.2 cubic inches (2.2L) engine
has a cylinder bore of 3.31" (84 mm), piston stroke of 3.94" (100 mm), and rated
power of 59.9 hp (47.7 kW).
The Massey Ferguson 1760M is fitted with 2 types of transmission. Type
1: Power shuttle transmission with 12 forward and 12 reverse gears. Type
2: Three-range hydrostatic transmission with infinite forward and
reverse gears.
Max. travel speed (forward/reverse): 20.9 mph (33.5 km/h) and 20.3 mph
(32.5 km/h). The open center hydraulic system used a gear pump with a
flow of 12.1 gpm (45.6 lpm). The hydraulic pressure is 165 bar (2395
psi). The Massey Ferguson 1760M is equipped with a power steering
system, internal wet disc brakes, 9.50x16 (AG) or 12x16.5 (Industrial)
front tires, and 13.6x28 (AG) or 18.4x24 (Industrial) rear tires. The
wheel base is 80.3" (2040 mm) for gear models and 77.9" (1980 mm) for
hydrostatic models. The tractor is compatible with the following
attachments: MF CB85 backhoe with digging depth of 101.6" (2580 mm), and
MF DL135 loader with maximum lift height of 110.2" (2790 mm).
| Engine Model |
Shibaura N4LDI-T |
| Engine Type |
4 stroke, direct injection, four cylinder diesel |
| Number of Cylinders |
4 |
| Displacement, cu in (L) |
135.2 (2.2) |
| Engine Bore, in (mm) |
3.31 (84.0) |
| Engine Stroke, in (mm) |
3.94 (100.0) |
| Rated Engine Power, hp (kW) |
59.9 (47.7) |
| Rated Engine Speed, rpm |
2600 |
| Aspiration |
Turbocharged |
| Fuel System |
Common rail direct injection |
| Fuel Tank Capacity, gal (L) |
10.6 (40) |
| Cooling System |
Liquid |
| Air Cleaner |
Dry Type |
| Emissions |
Tier 4 Final |
| Emission control |
Diesel Oxidation Catalyst (DOC) |
| Electrical System Rating, Volts |
12 |
| Charging System |
Electric Starter |
| PTO Operational Type |
Independent |
| PTO Horsepower (Gear Transmission), hp (kW) |
46.1 (34.4) |
| PTO Horsepower (Hydro Transmission), hp (kW) |
44.4 (33.1) |
| Rear PTO Clutch |
Electro-hydraulic |
| Rear PTO Shaft |
6-Spline, 13/8 inch |
| Rear PTO Speeds, rpm |
540 |
| Mid PTO |
Optional |
| Mid PTO Speeds, rpm |
2000 |
| Transmission Type |
Power shuttle |
| Gearbox Type |
12F/12R |
| Number of Forward Speeds |
12 |
| Number of Reverse Speeds |
12 |
| Clutch Type |
Single stage dry type |
| Shuttle Lever |
Electronic lever, left side of steering wheel |
| Maximum Forward Speed, mph (kph) |
17.8 (28.5) |
| Maximum Reverse Speed, mph (kph) |
17.5 (28.1) |
| Transmission Type |
Hydrostatic (Servo-HST) |
| Number of Forward Speeds |
Infinite (3-range) |
| Number of Reverse Speeds |
Infinite (3-range) |
| Maximum Forward Speed, mph (kph) |
20.9 (33.5) |
| Maximum Reverse Speed, mph (kph) |
20.3 (32.5) |
| Drive Wheels |
4WD 4x4 |
| Steering Configuration |
Front Steer |
| Steering System |
Power Steering |
| Service Brake |
Internal wet disc |
| Front Tire Size (Std) |
9.50x16 |
| Rear Tire Size (Std) |
13.6x28 |
| Front Tire Size (Lawn/Turf) |
27x10.50-15 |
| Rear Tire Size (Lawn/Turf) |
41x18.00-20 |
| Front Tire Size (Industrial) |
12-16.5 |
| Rear Tire Size (Industrial) |
18.4-24 |
| Hydraulic System Type |
Open center |
| Implement Pump Type |
Gear |
| Implement Pump Flow, gpm (Lpm) |
12.1 (45.6) |
| Hydraulic Pressure, Bar (psi) |
165 (2395) |
| Hydraulic Capacity, gpm (Lpm) |
12.7 (48.0) |
| Number of Standard Remote Valves (Rear) |
3 |
| 3-Point Hitch Category |
1 with extendable ball ends |
| Draft Sensing or Lift Control |
Position and draft control |
| Loader joystick |
Standard equipment, integrated into right hand console |
| Rear Arms |
Telescopic draft link ends |
| Lift Capacity 24-in (610 mm) behind pin (Gear Transmission), lb (kg) |
3310 (1500) |
| Lift Capacity 24-in (610 mm) behind pin (Hydro Transmission), lb (kg) |
3088 (1400) |
| Wheelbase (Gear), in (mm) |
80.3 (2040) |
| Wheelbase (Hydro), in (mm) |
77.9 (1980) |
| Length (Gear), in (mm) |
170.1 (4320) |
| Length (Hydro), in (mm) |
132.3 (3360) |
| Height (ROPS, Gear), in (mm) |
103.2 (2620) |
| Height (ROPS, Hydro), in (mm) |
102.4 (2600) |
| Height (Cab, Gear), in (mm) |
93.3 (2370) |
| Height (Cab, Hydro), in (mm) |
92.9 (2360) |
| Overall Width (Gear), in (mm) |
71.1 (1805) |
| Overall Width (Hydro), in (mm) |
65.4 (1660) |
| Weight (Cab, Gear), lb (kg) |
4474 (2120) |
| Weight (Cab, Hydro), lb (kg) |
4464 (2025) |
