New Holland TC45D Tractor
The
New Holland TC45D compact utility tractor was manufactured between 2001 and
2003. The New Holland TC45D driveline includes a Shibaura N844L 4-cylinder
indirect injection naturally aspirated water-cooled diesel engine with a rated
power of 45 kp (33.6 kW), and 4-range Dual Power hydrostatic transmission with
infinite forward and reverse gears.
Max forward speed - 17.2 mph (27.5 km/h), maximum reverse speed - 19.1
mph (30.5 km/h). The open center hydraulic system used a gear pump with
fluid flow rate of 9.8 gal/min (37.1 l/min). The main relief pressure is
160 bar (2275 psi). The New Holland TC45D is equipped with a power
steering system, wet disc brakes, 25x8.50-14 (2WD) or 27x8.50-15 (4WD)
front tires, and 44x18.00-20 (2WD) or 22.5LLx16.1 (4WD) rear tires.
The wheel base is 73.6" (1870 mm) for FWD models and 81" (2060 mm) for
SuperSteer models. The tractor is compatible with a
New Holland 16LA
front-end loader with a max lift height of 105" (2660 mm), or
New
Holland 17LA front-end loader with a max lift height of 106" (2690 mm).
| Engine Model |
Shibaura N844L |
| Engine Type |
4-Stroke, liquid-cooled diesel |
| Number of Cylinders |
4 |
| Displacement, cu in (L) |
135,2 (2,2) |
| Engine Bore, in (mm) |
3,31 (84,0) |
| Engine Stroke, in (mm) |
3,94 (100,0) |
| Rated Engine Power, hp (kW) |
45,0 (33,6) |
| Rated Engine Speed, rpm |
2600 |
| Low Idle Speed, rpm |
1025 |
| Compression Ratio |
22.5:1 |
| Firing Order |
1-3-4-2 |
| Fuel Pump Type |
In-Line |
| Aspiration |
Naturally aspirated |
| Fuel System |
Indirect injection |
| Cooling System Type |
Pressurized Liquid with Recirculating Bypass |
| Water Pump Type |
Centrifugal |
| Drive Belt |
V-Belt |
| Fuel Tank Capacity, gal (L) |
13,0 (54,5) |
| Oil Capacity, qts (L) |
6,3 (6,0) |
| Coolant Capacity, qts (L) |
8,4 (8,0) |
| Electrical System Rating, Volts |
12 |
| Alternator Rating, Amps |
40 |
| Battery Type |
Negative ground, 600 cca |
| PTO Operational Type |
Independent |
| PTO Horsepower, hp (kW) |
27,7 (20,8) |
| Rear PTO / Engine Speeds, rpm |
540/2400 |
| Rear PTO Shaft, in (mm) |
1,38 (35,0) |
| Mid PTO / Engine Speeds, rpm |
2000/2420 |
| Mid PTO Shaft, in (mm) |
1,0 (25,3) |
| Transmission Model |
Dual Power |
| Transmission Type |
Hydrostatic (HST) |
| Number of Forward Gears |
Infinite (4-range) |
| Number of Reverse Gears |
Infinite (4-range) |
| Motor Speed Shift |
Electric Switch |
| Maximum Speed (Forward), mph (kph) |
17,2 (27,5) |
| Maximum Speed (Reverse), mph (kph) |
19,1 (30,5) |
| Drive Wheels |
2WD/4WD |
| Steering Configuration |
Front Steer |
| Steering System |
Power |
| Service Brake |
Wet Disc |
| Front Tire Size (2WD) |
25x8.50-14 |
| Rear Tire Size (2WD) |
44x18-20 |
| Front Tire Size (4WD) |
27x8.50-15 |
| Rear Tire Size (4WD) |
22.5LLx16.1 |
| Hydraulic System Type |
Open Center |
| Implement Pump Type |
Gear |
| Implement Pump Flow, gpm (Lpm) |
9,8 (37,1) |
| Steering Pump Flow, gpm (Lpm) |
5,3 (19,4) |
| Hydraulic Pressure, Bar (psi) |
160 (2275) |
| Number of Standard Remote Valves (Rear/Mid) |
3/2 |
| 3-Point Hitch Category |
1 |
| Draft Sensing or Lift Control |
Hydraulic Position Control and Top Link Sensing |
| Standard Lift Capacity 24" (600 mm) behind pin, lb (kg) |
2330 (1060) |
| Drop Rate Control |
Standard |
| Wheelbase (FWD), in (mm) |
73,6 (1870) |
| Wheelbase (SuperSteer), in (mm) |
81,0 (2060) |
| Length (FWD), in (mm) |
125,2 (3181) |
| Length (SuperSteer), in (mm) |
129,6 (3290) |
| Height, in (mm) |
95,5 (2430) |
| Overall Width, in (mm) |
84,5 (2146) |
| Ground Clearance (FWD), in (mm) |
14 (356) |
| Ground Clearance (SuperSteer), in (mm) |
11,5 (292) |
| Turning Radius (FWD), in (mm) |
127,5 (3240) |
| Turning Radius (SuperSteer), in (mm) |
113 (2870) |
| Weight (FWD), lb (kg) |
3420 (1550) |
| Weight (SuperSteer), lb (kg) |
3590 (1630) |
